    Wheat Straw Pulp Evaporation Station With Five Effect Pillow Plate Evaporator

    Ask Lasest Price
    Brand Name : HANPU
    Model Number : HP-MEE
    Certification : ISO,CE
    Price : 200,000USD~1,000,000USD/SET
    Payment Terms : T/T,L/C,D/A,D/P,Western Union
    Supply Ability : 1 set/ 90days
    Delivery Time : 90 days
    • Product Details
    • Company Profile

    Wheat Straw Pulp Evaporation Station With Five Effect Pillow Plate Evaporator

    Wheat Straw Pulp Evaporation Station with Five-Effect Pillow Plate Evaporator
    Hanpu supplies a high-efficiency five-effect evaporation station engineered for wheat straw pulp mills. Using pillow plate (dimple plate) heat-exchange technology and falling-film hydraulics, the system concentrates black liquor or filtrates with low fouling, stable operation, and best-in-class steam economy—ready for chemical recovery or downstream crystallization.
    Energy Saving
    Five effects in series reuse vapor enthalpy, delivering a steam economy typically 4.0–5.5 kg water/kg steam, cutting boiler load and CO₂ emissions.
    Low Fouling on Fibrous Streams
    Pillow plate channels promote turbulence with wide cross-sections, reducing scaling and fiber deposition commonly seen with straw-derived liquors.
    Compact & Maintainable
    Lightweight plates allow tight footprints, easy access for inspection, and rapid plate replacement compared with bulky shell-and-tube bundles.
    Recovery-Ready
    Clean condensate reuse, optional strip-ping of volatiles, and NCG handling help meet environmental limits and improve alkali recovery performance.
    Process Description
    1. Feed preheat: Inlet liquor is preheated by condensate/flash vapor to minimize live steam.
    2. Five-effect falling film: Even distribution over pillow plate panels; each downstream effect operates at lower pressure/temperature to cascade heat.
    3. Vapor–liquid separation: High-efficiency demisters avoid entrainment; clean condensate is recovered.
    4. Vacuum & NCG management: Surface condenser with vacuum pump removes non-condensables and controls TRS/odor.
    5. Automation: PLC/HMI with recipes, trend logs, and surge protection; inline density/solids for set-point control.
    6. Cleaning: Online water wash, alkaline/acid CIP, and optional piggable lines mitigate organic/inorganic fouling.
    Materials & Compliance
    • Metals: SS304/SS316L standard; Duplex 2205/2507 for chloride/alkali resistance in black liquor service.
    • Gaskets & seals: EPDM/FKM/PTFE per temperature and chemical exposure.
    • Standards: ASME/PED vessels, CE marking available; safety interlocks and pressure protection included.
    Technical Snapshot
    ItemTypical Range / Note
    ApplicationWheat straw pulp liquor, filtrates, and side streams prior to recovery or crystallization
    Evaporation capacity10–120 t/h per line (customizable by effect area and plate count)
    EffectsFive-effect (optional TVR on selected effects to boost economy)
    Steam economy~4.0–5.5 kg water/kg live steam (feed and ΔT dependent)
    Operating temperaturesFirst effect ~95–105 °C → last effect ~55–65 °C (under vacuum; BPE considered)
    Product outlet solidsTailored to recovery boiler or crystallizer target; typical 45–65% TS
    ControlsPLC/HMI, flow/level/pressure/temperature, density/°Brix (where relevant), condensate conductivity
    CIPAutomated alkaline/acid/hot water cycles; online wash between batches or on condition
    FootprintCompact modular skids with accessible plate packs and separators
    Options & Enhancements
    • Condensate stripping column for VOC/TRS reduction and water reuse.
    • NCG collection with safe routing to oxidizer or recovery boiler.
    • Heat-integrated preheaters and flash tanks to maximize internal energy recovery.
    • MVR or additional TVR stages for higher electrical/steam flexibility.
    Manufacturing & Assembly
    Delivery Workflow
    Feed data & targets → Thermal design & heat/mass balance → Pilot validation (optional) → Detailed engineering → Fabrication & FAT → Installation & commissioning → Performance test & training → Lifecycle service & spares.
    Values shown are typical. Final design depends on liquor composition, BPE, viscosity curve, scaling tendency, and site utilities.
